Apache CloudStack — A Production Deployment Guide

Part 1 — Foundations · Building a Sovereign Cloud on Apache CloudStack 4.22.1.0 LTS

Michael Hinsley

When a license renewal lands at 567% of last year's bill, renting your infrastructure stops being a strategy. This is the escape tunnel: a complete production build of Apache CloudStack 4.22 LTS — KVM, Ceph, SONiC leaf-spine — across a three-city UK estate, written by an engineer with 32 years of building the real thing. Own your cloud down to the last packet.

Minimum price

$19.99

$34.99

You pay

Author earns

$

Also available for 1 book credit with a Reader Membership

Buying multiple copies for your team? See below for a discount!

PDF
EPUB
About

About

About the Book

For a decade the industry outsourced its thinking and treated hypervisors like electricity. Then the landlord changed the locks. When the renewal letter lands at 567% of last year's bill, it isn't a price rise — for many organisations it's an extinction event.

This book is the escape tunnel. It follows a fictional UK publisher, Leaf Spine Books, out of a strangling licensing model and onto a sovereign platform they own down to the last packet: Apache CloudStack 4.22.1.0 LTS on KVM, Ceph storage deployed with cephadm, and a SONiC leaf-spine fabric on open networking switches — a three-city estate (Manchester, London, Leeds)

.

Part 1 — Foundations (Chapters 1–18) takes you from the renewal letter to a live, multi-zone production cloud:

  • Design and economics — the full three-city blueprint: hardware, VLAN and IP plans, GPU capacity from day one, and honest arithmetic on what sovereignty actually costs
  • A lab you can break — the whole design in miniature on one second-hand server, so every mistake costs an evening rather than a career
  • The production build — hardened Ubuntu hosts, a MariaDB Galera control-plane database, HA management servers, DRBD/NFS secondary storage, and a six-node NVMe Ceph RBD cluster, each layer drilled against real failure before the next goes on top
  • The cloud goes live — zone deployment, KVM compute clusters, GPU passthrough, first guest workloads, VPC multi-tier networking, and the SONiC fabric built for real
  • Running it like you mean it — multi-zone expansion, federated monitoring, sovereign alerting, backup and disaster recovery with an independent-fate cluster, and cost optimisation that turns raw usage into a defensible bill

Every number is labelled for what it is — measured, forecast, or illustration — and every procedure is meant to be rehearsed in a lab before it touches production. The method is yours to take, adapt, and run on hardware you own.
