Using Property Graph Database with Ollama

  1 import ladybug
  2 from langchain_community.chains.graph_qa.cypher import GraphCypherQAChain
  3 from langchain_community.graphs.graph_store import GraphStore
  4 from langchain_ollama.llms import OllamaLLM
  5 import sys
  6 from pathlib import Path
  7
  8 ROOT = Path(__file__).resolve().parents[1]
  9 if str(ROOT) not in sys.path:
 10     sys.path.insert(0, str(ROOT))
 11
 12 from ollama_config import get_client, get_model
 13 import shutil
 14
 15 db_path = "test_db"
 16 if Path(db_path).exists():
 17     shutil.rmtree(db_path)
 18
 19 db = ladybug.Database(db_path)
 20 conn = ladybug.Connection(db)
 21
 22
 23 # ---------------------------------------------------------------------------
 24 # Custom LadybugGraph wrapper for LangChain's GraphCypherQAChain
 25 # ---------------------------------------------------------------------------
 26 class LadybugGraph(GraphStore):
 27     """Minimal LangChain graph wrapper around a LadybugDB connection."""
 28
 29     def __init__(self, database, allow_dangerous_requests: bool = False):
 30         self._db = database
 31         self._conn = ladybug.Connection(database)
 32         self._allow_dangerous_requests = allow_dangerous_requests
 33         self._schema = ""
 34         self.refresh_schema()
 35
 36     @property
 37     def get_schema(self) -> str:
 38         return self._schema
 39
 40     @property
 41     def get_structured_schema(self) -> dict:
 42         return {"schema": self._schema}
 43
 44     def refresh_schema(self) -> None:
 45         """Build a human-readable schema string from the database metadata."""
 46         node_tables = []
 47         rel_tables = []
 48         try:
 49             result = self._conn.execute("CALL show_tables() RETURN *;")
 50             while result.has_next():
 51                 row = result.get_next()
 52                 table_name = row[1] if len(row) > 1 else row[0]
 53                 table_type = row[2] if len(row) > 2 else ""
 54                 if table_type == "NODE":
 55                     node_tables.append(table_name)
 56                 elif table_type == "REL":
 57                     rel_tables.append(table_name)
 58         except Exception:
 59             pass
 60
 61         parts = []
 62         for nt in node_tables:
 63             try:
 64                 props_result = self._conn.execute(
 65                     f"CALL table_info('{nt}') RETURN *;"
 66                 )
 67                 props = []
 68                 while props_result.has_next():
 69                     prow = props_result.get_next()
 70                     props.append(f"{prow[1]}: {prow[2]}")
 71                 parts.append(f"Node: {nt} ({', '.join(props)})")
 72             except Exception:
 73                 parts.append(f"Node: {nt}")
 74
 75         for rt in rel_tables:
 76             parts.append(f"Relationship: {rt}")
 77
 78         self._schema = "\n".join(parts) if parts else "No schema available."
 79
 80     def query(self, query: str, params: dict = None) -> list[dict]:
 81         """Execute a Cypher query and return results as list of dicts."""
 82         try:
 83             result = self._conn.execute(query)
 84             columns = result.get_column_names()
 85             rows = []
 86             while result.has_next():
 87                 values = result.get_next()
 88                 rows.append(dict(zip(columns, values)))
 89             return rows
 90         except Exception as e:
 91             return [{"error": str(e)}]
 92
 93     def add_graph_documents(self, graph_documents, include_source=False):
 94         raise NotImplementedError("Use Cypher queries to add data.")
 95
 96 # Create two tables and a relation: Movie, Person, ActedIn
 97 conn.execute("CREATE NODE TABLE Movie (name STRING, PRIMARY KEY(name))")
 98 conn.execute(
 99     "CREATE NODE TABLE Person (name STRING, birthDate STRING, PRIMARY KEY(name))"
100 )
101 conn.execute("CREATE REL TABLE ActedIn (FROM Person TO Movie)")
102 conn.execute("CREATE (:Person {name: 'Al Pacino', birthDate: '1940-04-25'})")
103 conn.execute("CREATE (:Person {name: 'Robert De Niro', birthDate: '1943-08-17'})")
104 conn.execute("CREATE (:Movie {name: 'The Godfather'})")
105 conn.execute("CREATE (:Movie {name: 'The Godfather: Part II'})")
106 conn.execute(
107     "CREATE (:Movie {name: 'The Godfather Coda: The Death of Michael Corleone'})"
108 )
109 conn.execute(
110     "MATCH (p:Person), (m:Movie) WHERE p.name = 'Al Pacino' AND m.name = 'The Godfather' CREATE (p)-[:ActedIn]->(m)"
111 )
112 conn.execute(
113     "MATCH (p:Person), (m:Movie) WHERE p.name = 'Al Pacino' AND m.name = 'The Godfather: Part II' CREATE (p)-[:ActedIn]->(m)"
114 )
115 conn.execute(
116     "MATCH (p:Person), (m:Movie) WHERE p.name = 'Al Pacino' AND m.name = 'The Godfather Coda: The Death of Michael Corleone' CREATE (p)-[:ActedIn]->(m)"
117 )
118 conn.execute(
119     "MATCH (p:Person), (m:Movie) WHERE p.name = 'Robert De Niro' AND m.name = 'The Godfather: Part II' CREATE (p)-[:ActedIn]->(m)"
120 )
121
122 conn.execute("CREATE (:Person {name: 'Marlon Brando', birthDate: '1924-04-03'})")
123 conn.execute("CREATE (:Person {name: 'Diane Keaton', birthDate: '1946-01-05'})")
124 conn.execute("CREATE (:Movie {name: 'Apocalypse Now'})")
125 conn.execute("CREATE (:Movie {name: 'Annie Hall'})")
126
127 conn.execute(
128     "MATCH (p:Person), (m:Movie) WHERE p.name = 'Marlon Brando' AND m.name = 'Apocalypse Now' CREATE (p)-[:ActedIn]->(m)"
129 )
130 conn.execute(
131     "MATCH (p:Person), (m:Movie) WHERE p.name = 'Diane Keaton' AND m.name = 'Annie Hall' CREATE (p)-[:ActedIn]->(m)"
132 )
133 conn.execute(
134     "MATCH (p:Person), (m:Movie) WHERE p.name = 'Diane Keaton' AND m.name = 'The Godfather: Part II' CREATE (p)-[:ActedIn]->(m)"
135 )
136 conn.execute(
137     "MATCH (p:Person), (m:Movie) WHERE p.name = 'Al Pacino' AND m.name = 'Apocalypse Now' CREATE (p)-[:ActedIn]->(m)"
138 )
139
140 from langchain_ollama import ChatOllama
141 from langchain_core.prompts import ChatPromptTemplate
142 from langchain_core.runnables import RunnableLambda
143
144 graph = LadybugGraph(db, allow_dangerous_requests=True)
145
146 # Use ChatOllama for better instruction following
147 base_llm = ChatOllama(
148     model=get_model(),
149     temperature=0,
150 )
151
152 # Custom prompt using ChatPromptTemplate
153 CYPHER_GENERATION_PROMPT = ChatPromptTemplate.from_messages([
154     ("system", """You are a Cypher expert for a property graph database. Generate ONLY the Cypher query.
155 Rules:
156 1. Do NOT use 'GROUP BY' or 'HAVING'. Cypher performs grouping implicitly.
157 2. For filtering on aggregations, use 'WITH' and 'WHERE'.
158 3. Start directly with MATCH or other Cypher keywords.
159 4. No preamble, no explanation, no markdown."""),
160     ("human", """Schema:
161 {schema}
162
163 Example:
164 Question: Which actors appeared in more than one movie?
165 Cypher: MATCH (p:Person)-[:ActedIn]->(m:Movie) WITH p.name AS name, COUNT(m) AS count WHERE count > 1 RETURN name
166
167 Question: {question}
168 Cypher Query:""")
169 ])
170
171 def clean_cypher_output(output):
172     """Clean the LLM output to extract only the Cypher query."""
173     content = output.content if hasattr(output, 'content') else str(output)
174
175     # Remove markdown code blocks if present
176     content = content.replace("```cypher", "").replace("```", "").strip()
177
178     # Heuristic: Find the first Cypher keyword and strip everything before it
179     keywords = ["MATCH", "CREATE", "MERGE", "RETURN", "WITH", "UNWIND"]
180     for keyword in keywords:
181         if keyword in content.upper():
182             idx = content.upper().find(keyword)
183             content = content[idx:]
184             break
185
186     # Take only the first line to avoid any trailing explanations
187     return content.split("\n")[0].strip()
188
189 # Create a runnable that cleans the output
190 cypher_llm = base_llm | RunnableLambda(clean_cypher_output)
191
192 # Create a chain using GraphCypherQAChain with our custom LadybugGraph wrapper
193 chain = GraphCypherQAChain.from_llm(
194     llm=cypher_llm,
195     qa_llm=base_llm,
196     graph=graph,
197     verbose=True,
198     allow_dangerous_requests=True,
199     cypher_prompt=CYPHER_GENERATION_PROMPT,
200 )
201
202 print(graph.get_schema)
203
204 # Ask two questions
205 chain.invoke("Who acted in The Godfather: Part II?")
206 chain.invoke("Robert De Niro played in which movies?")
207 chain.invoke("Which actors acted in Apocalypse Now?")
208 chain.invoke("What movies did Diane Keaton act in?")
209 chain.invoke("Which actors appeared in more than one movie in the database?")

 1 $ rm -rf test_db
 2 $ uv run graph_ladybug_property_example.py
 3 Node: Movie (name: STRING)
 4 Node: Person (name: STRING, birthDate: STRING)
 5 Relationship: ActedIn
 6
 7 > Entering new GraphCypherQAChain chain...
 8 Generated Cypher:
 9 MATCH (p:Person)-[:ActedIn]->(m:Movie) WHERE m.name = 'The Godfather: Part II' RETURN p.name
10 Full Context:
11 [{'p.name': 'Al Pacino'}, {'p.name': 'Robert De Niro'}, {'p.name': 'Diane Keaton'}]
12
13 > Finished chain.
14
15 > Entering new GraphCypherQAChain chain...
16 Generated Cypher:
17 MATCH (p:Person {name: 'Robert De Niro'})-[:ActedIn]->(m:Movie) RETURN m.name AS movieName
18 Full Context:
19 [{'movieName': 'The Godfather: Part II'}]
20
21 > Finished chain.
22
23 > Entering new GraphCypherQAChain chain...
24 Generated Cypher:
25 MATCH (p:Person)-[:ActedIn]->(m:Movie) WHERE m.name = 'Apocalypse Now' RETURN p.name AS actor
26 Full Context:
27 [{'actor': 'Al Pacino'}, {'actor': 'Marlon Brando'}]
28
29 > Finished chain.
30
31 > Entering new GraphCypherQAChain chain...
32 Generated Cypher:
33 MATCH (p:Person {name: 'Diane Keaton'})-[:ActedIn]->(m:Movie) RETURN m.name AS movieName;
34 Full Context:
35 [{'movieName': 'The Godfather: Part II'}, {'movieName': 'Annie Hall'}]
36
37 > Finished chain.
38
39 > Entering new GraphCypherQAChain chain...
40 Generated Cypher:
41 MATCH (p:Person)-[:ActedIn]->(m:Movie) WITH p.name AS name, COUNT(m) AS count WHERE count > 1 RETURN name
42 Full Context:
43 [{'name': 'Diane Keaton'}, {'name': 'Al Pacino'}]
44
45 > Finished chain.

1 MATCH (p:Person)-[:ActedIn]->(m:Movie {name: 'The Godfather: Part II'})
2 RETURN p.name

  1 """
  2 Created by Claude Sonnet 3.5 from prompt:
  3
  4 Given some text, I want you to define Property graph schemas for
  5 the information in the text. As context, here is some Python code
  6 for defining two tables and a relation and querying the data:
  7
  8 [[CODE FROM graph_ladybug_property_example.py]]
  9
 10 NOW, HERE IS THE TEST TO CREATE SCHEME FOR, and to write code to
 11 create nodes and links conforming to the scheme:
 12
 13 [[CONTENTS FROM FILE data/economics.txt]]
 14
 15 """
 16
 17 import ladybug
 18
 19 db = ladybug.Database("economics_db")
 20 conn = ladybug.Connection(db)
 21
 22 # Node tables
 23 conn.execute("""
 24 CREATE NODE TABLE School (
 25     name STRING,
 26     description STRING,
 27     PRIMARY KEY(name)
 28 )""")
 29
 30 conn.execute("""
 31 CREATE NODE TABLE Economist (
 32     name STRING,
 33     birthDate STRING,
 34     PRIMARY KEY(name)
 35 )""")
 36
 37 conn.execute("""
 38 CREATE NODE TABLE Institution (
 39     name STRING,
 40     type STRING,
 41     PRIMARY KEY(name)
 42 )""")
 43
 44 conn.execute("""
 45 CREATE NODE TABLE EconomicConcept (
 46     name STRING,
 47     description STRING,
 48     PRIMARY KEY(name)
 49 )""")
 50
 51 # Relationship tables
 52 conn.execute("CREATE REL TABLE FoundedBy (FROM School TO Economist)")
 53 conn.execute("CREATE REL TABLE TeachesAt (FROM Economist TO Institution)")
 54 conn.execute("CREATE REL TABLE Studies (FROM School TO EconomicConcept)")
 55
 56 # Insert some data
 57 conn.execute("CREATE (:School {name: 'Austrian School', description: 'School of economic thought emphasizing spontaneous organizing power of price mechanism'})")
 58
 59 # Create economists
 60 conn.execute("CREATE (:Economist {name: 'Carl Menger', birthDate: 'Unknown'})")
 61 conn.execute("CREATE (:Economist {name: 'Eugen von Böhm-Bawerk', birthDate: 'Unknown'})")
 62 conn.execute("CREATE (:Economist {name: 'Ludwig von Mises', birthDate: 'Unknown'})")
 63 conn.execute("CREATE (:Economist {name: 'Pauli Blendergast', birthDate: 'Unknown'})")
 64
 65 # Create institutions
 66 conn.execute("CREATE (:Institution {name: 'University of Krampton Ohio', type: 'University'})")
 67
 68 # Create economic concepts
 69 conn.execute("CREATE (:EconomicConcept {name: 'Microeconomics', description: 'Study of individual agents and markets'})")
 70 conn.execute("CREATE (:EconomicConcept {name: 'Macroeconomics', description: 'Study of entire economy and issues affecting it'})")
 71
 72 # Create relationships
 73 conn.execute("""
 74 MATCH (s:School), (e:Economist)
 75 WHERE s.name = 'Austrian School' AND e.name = 'Carl Menger'
 76 CREATE (s)-[:FoundedBy]->(e)
 77 """)
 78
 79 conn.execute("""
 80 MATCH (s:School), (e:Economist)
 81 WHERE s.name = 'Austrian School' AND e.name = 'Eugen von Böhm-Bawerk'
 82 CREATE (s)-[:FoundedBy]->(e)
 83 """)
 84
 85 conn.execute("""
 86 MATCH (s:School), (e:Economist)
 87 WHERE s.name = 'Austrian School' AND e.name = 'Ludwig von Mises'
 88 CREATE (s)-[:FoundedBy]->(e)
 89 """)
 90
 91 conn.execute("""
 92 MATCH (e:Economist), (i:Institution)
 93 WHERE e.name = 'Pauli Blendergast' AND i.name = 'University of Krampton Ohio'
 94 CREATE (e)-[:TeachesAt]->(i)
 95 """)
 96
 97 # Link school to concepts it studies
 98 conn.execute("""
 99 MATCH (s:School), (c:EconomicConcept)
100 WHERE s.name = 'Austrian School' AND c.name = 'Microeconomics'
101 CREATE (s)-[:Studies]->(c)
102 """)
103
104 """
105 Code written from the prompt:
106
107 Now that you have written code to create a sample graph database about
108 economics, you can write queries to extract information from the database.
109 """
110
111 def query_and_print_result(query):
112     """Basic pretty printer for Ladybug query results"""
113     print(f"\n* Processing: {query}")
114     result = conn.execute(query)
115     if not result:
116         print("No results found")
117         return
118
119     # Get column names
120     while result.has_next():
121         r = result.get_next()
122         print(r)
123
124 # 1. Find all founders of the Austrian School
125 query_and_print_result("""
126 MATCH (s:School)-[:FoundedBy]->(e:Economist)
127 WHERE s.name = 'Austrian School'
128 RETURN e.name
129 """)
130
131 # 2. Find where Pauli Blendergast teaches
132 query_and_print_result("""
133 MATCH (e:Economist)-[:TeachesAt]->(i:Institution)
134 WHERE e.name = 'Pauli Blendergast'
135 RETURN i.name, i.type
136 """)
137
138 # 3. Find all economic concepts studied by the Austrian School
139 query_and_print_result("""
140 MATCH (s:School)-[:Studies]->(c:EconomicConcept)
141 WHERE s.name = 'Austrian School'
142 RETURN c.name, c.description
143 """)
144
145 # 4. Find all economists and their institutions
146 query_and_print_result("""
147 MATCH (e:Economist)-[:TeachesAt]->(i:Institution)
148 RETURN e.name as Economist, i.name as Institution
149 """)
150
151 # 5. Find schools and count their founders
152 query_and_print_result("""
153 MATCH (s:School)-[:FoundedBy]->(e:Economist)
154 RETURN s.name as School, COUNT(e) as NumberOfFounders
155 """)
156
157 # 6. Find economists who both founded schools and teach at institutions
158 query_and_print_result("""
159 MATCH (s:School)-[:FoundedBy]->(e:Economist)-[:TeachesAt]->(i:Institution)
160 RETURN e.name as Economist, s.name as School, i.name as Institution
161 """)
162
163 # 7. Find economic concepts without any schools studying them
164 query_and_print_result("""
165 MATCH (c:EconomicConcept)
166 WHERE NOT EXISTS {
167     MATCH (s:School)-[:Studies]->(c)
168 }
169 RETURN c.name
170 """)
171
172 # 8. Find economists with no institutional affiliations
173 query_and_print_result("""
174 MATCH (e:Economist)
175 WHERE NOT EXISTS {
176     MATCH (e)-[:TeachesAt]->()
177 }
178 RETURN e.name
179 """)
