Deep Learning Introduction

Apple’s work in smoothly integrating deep learning into their developer tools for macOS, iOS, and iPadOS applications is in my opinion nothing short of brilliant. We will finish this book with an application that uses two deep learning models that provide almost all of the functionality of the application.

Before diving into Apple’s CoreML libraries in later chapters we will take a shallow dive into the principles of deep learning and take a lay-of-the-land look at the type of most commonly used models. This chapter has no example programs and is intended as background material.

Most of my professional career since 2014 has involved Deep Learning, mostly with TensorFlow using the Keras APIs. In the late 1980s I was on a DARPA neural network technology advisory panel for a year, I wrote the first prototype of the SAIC ANSim neural network library commercial product, and I wrote the neural network prediction code for a bomb detector my company designed and built for the FAA for deployment in airports. More recently I have used GAN (generative adversarial networks) models for synthesizing numeric spreadsheet data and LSTM (long short term memory) models to synthesize highly structured text data like nested JSON and for NLP (natural language processing). I have also written a product recommendation model for an online store using TensorFlow Recommenders. I have several USA and European patents using neural network and Deep Learning technology.

Here we will learn a vocabulary for discussing Deep Learning neural network models and look at possible architectures.

If you want to use Deep Learning professionally, there are two specific online resources that I recommend: Andrew Ng leads the efforts at deeplearning.ai and Jeremy Howard leads the efforts at fast.ai.

There are many Deep Learning neural architectures in current practical use; a few types that I use are:

• Multi-layer perceptron networks with many fully connected layers. An input layer contains placeholders for input data. Each element in the input layer is connected by a two-dimensional weight matrix to each element in the first hidden layer. We can use any number of fully connected hidden layers, with the last hidden layer connected to an output layer.
• Convolutional networks for image processing and text classification. Convolutions, or filters, are small windows that can process input images (filters are two-dimensional) or sequences like text (filters are one-dimensional). Each filter uses a single set of learned weights independent of where the filter is applied in an input image or input sequence.
• Autoencoders have the same number of input layer and output layer elements with one or more hidden fully connected layers. Autoencoders are trained to produce the same output as training input values using a relatively small number of hidden layer elements. Autoencoders are capable of removing noise in input data.
• LSTM (long short term memory) process elements in a sequence in order and are capable of remembering patterns that they have seen earlier in the sequence.
• GAN (generative adversarial networks) models comprise two different and competing neural models, the generator and the discriminator. GANs are often trained on input images (although in my work I have applied GANs to two-dimensional numeric spreadsheet data). The generator model takes as input a “latent input vector” (this is just a vector of specific size with random values) and generates a random output image. The weights of the generator model are trained to produce random images that are similar to how training images look. The discriminator model is trained to recognize if an arbitrary output image is original training data or an image created by the generator model. The generator and discriminator models are trained together.

The core functionality of libraries like TensorFlow are written in C++ and take advantage of special hardware like GPUs, custom ASICs, and devices like Google’s TPUs. Most people who work with Deep Learning models don’t need to even be aware of the low level optimizations used to make training and using Deep Learning models more efficient. That said, in the following section I am going to show you how simple neural networks are trained and used.

Simple Multi-layer Perceptron Neural Networks

I use the terms Multi-layer perceptron neural networks, backpropagation neural networks and delta-rule networks interchangeably. Backpropagation refers to the model training process of calculating the output errors when training inputs are passed in the forward direction from input layer, to hidden layers, and then to the output layer. There will be an error which is the difference between the calculated outputs and the training outputs. This error can be used to adjust the weights from the last hidden layer to the output layer to reduce the error. The error is then backprogated backwards through the hidden layers, updating all weights in the model. I have detailed example code in several of my older artificial intelligence books. Here I am satisfied to give you an intuition of how simple neural networks are trained.

The basic idea is that we start with a network initialized with random weights and for each training case we propagate the inputs through the network towards the output neurons, calculate the output errors, and back-up the errors from the output neurons back towards the input neurons in order to make small changes to the weights to lower the error for the current training example. We repeat this process by cycling through the training examples many times.

The following figure shows a simple backpropagation network with one hidden layer. Neurons in adjacent layers are connected by floating point connection strength weights. These weights start out as small random values that change as the network is trained. Weights are represented in the following figure by arrows; in the code the weights connecting the input to the output neurons are represented as a two-dimensional array.

Each non-input neuron has an activation value that is calculated from the activation values of connected neurons feeding into it, gated (adjusted) by the connection weights. For example, in the above figure, the value of Output 1 neuron is calculated by summing the activation of Input 1 times weight W1,1 and Input 2 activation times weight W2,1 and applying a “squashing function” like Sigmoid or Relu (see figures below) to this sum to get the final value for Output 1’s activation value. We want to flatten activation values to a relatively small range but still maintain relative values. To do this flattening we use the Sigmoid function that is seen in the next figure, along with the derivative of the Sigmoid function which we will use in the code for training a network by adjusting the weights.

Simple neural network architectures with just one or two hidden layers are easy to train using backpropagation and I have from scratch code (using no libraries) for this several of my previous books. However, here we are using Hy to write models using the TensorFlow framework which has the huge advantage that small models you experiment with on your laptop can be scaled to more parameters (usually this means more neurons in hidden layers which increases the number of weights in a model) and run in the cloud using multiple GPUs.

Except for pedantic purposes, I now never write neural network code from scratch. I take instead advantage of the many person-years of engineering work put into the development of frameworks like TensorFlow, PyTorch, mxnet, etc. We now move on to two examples built with TensorFlow.

Deep Learning

Deep Learning models are generally understood to have many more hidden layers than simple multi-layer perceptron neural networks and often comprise multiple simple models combined together in series or in parallel. Complex architectures can be iteratively developed by manually adjusting the size of model components, changing the components, etc. Alternatively, model architecture search can be automated. At Capital One I used Google’s AdaNet project that efficiently searches for effective model architectures inside a single TensorFlow session. Now all major cloud compute provides support some form of AutoML. You need to make a decision for yourself how much effort you want to put into deeply understanding the technology, or simply learning how to use pre-trained models.
