Logic Programming with Racklog: Two Classic Problems Revisited

In the previous chapter we used OPS5, a forward-chaining production rule system, to solve two classic problems: analyzing a poker hand and planning how a monkey can reach bananas hanging from a ceiling. In this chapter we solve the same two problems with Racklog, a Prolog-style logic programming library embedded in Racket. Keeping the problems identical lets us focus on what actually changed: the reasoning strategy.

A production system like OPS5 reasons forward. Facts sit in a working memory. Rules continuously pattern-match against those facts, and whenever a rule’s conditions are satisfied it fires, adding or modifying facts. The program never states a goal explicitly; the desired outcome emerges when the match-fire loop has transformed the initial facts into the final ones. You saw this in the monkey example: rules mb1 through mb18 fired one after another, narrating the monkey’s actions until the goal fact was marked satisfied.

Logic programming reasons backward. We define relations (facts and rules that describe what is true) and then pose a query. The system works backward from the query, trying to prove it by unifying it against the heads of rules and recursively proving their bodies, backtracking whenever a choice fails. The query itself names the goal, and the answer is the set of variable bindings that make the query true.

In forward chaining we say “whenever you see this situation, do this.” In backward chaining we say “here is what it means to reach the goal; find me a way.” For the monkey problem, the difference is vivid: OPS5 performs the plan step by step, while Racklog searches for a plan and returns it as the answer to a question.

Racklog is not a separate language you shell out to; it is an ordinary Racket library. Logic variables, unification, and backtracking are implemented as Racket macros and procedures, so a logic program lives inside a normal #lang racket file and can call, and be called by, regular Racket code.

Recall the draw poker example. The hand we analyze is exactly the one we gave OPS5:

• 10 of hearts
• 10 of diamonds
• 10 of clubs
• 4 of diamonds

We want to find every pair and every three of a kind. In OPS5 we wrote productions that watched working memory and asserted pair and three facts. In Racklog we do something simpler: the hand itself is a relation, and “pair” and “three of a kind” are derived relations defined by rules over it.

A Racklog relation is defined with %rel, which takes a list of logic variables followed by clauses. Each clause has a head (the argument pattern) and an optional body of goals that must all succeed. One syntactic detail matters: clause heads are ordinary Racket expressions, so constant symbols are quoted ('heart) and compound terms are built with list.

Here is the complete file draw.rkt:

The %card relation is pure data: four facts, one per card. The interesting part is %pair. Its single clause says: (s1 s2 n) is a pair if %card holds for suit s1 at rank n, %card holds for a different suit s2 at the same rank n, and s1 sorts before s2. Because the logic variable n appears in both %card goals, unification forces both cards to share a rank. That single shared variable does the work that the OPS5 rule expressed with the pattern (card <suit> <num>) matched twice against working memory.

The %suit< relation deserves a second look. The OPS5 version used negated conditions like -(pair <suit2> <suit> <num>) to avoid reporting the same pair twice in different orders. In logic programming we get the same effect declaratively: by requiring s1 to come before s2 in a fixed suit ordering, each unordered combination is generated exactly once, and no bookkeeping facts are needed.

The two %find-all forms at the bottom are the bridge back to ordinary Racket. %find-all runs a query, collects every solution, and returns a plain Racket list of association lists, which we then print with an everyday for loop. %which (used in the next example) returns just the first solution, and %more would backtrack to the next one.

Three cards share the rank 10, and three cards taken two at a time give exactly three pairs, which is exactly what the program reports. The lone 4 of diamonds participates in nothing and correctly never appears in the output. The single three of a kind uses all three 10s.

Compare the shape of the two solutions. The OPS5 program was about events: rules firing, facts appearing in working memory. This program contains no events at all: %pair is a timeless statement about what “pair” means, and the three lines of output are simply every way the statement can be made true for this hand. The cost of that elegance is that control is implicit: the order in which solutions are found depends on clause order and Racklog’s depth-first search, something we will see matter more in the next example.

The monkey problem is a planning problem, and it is where the two paradigms diverge most. Recall the scenario: a monkey is on a couch at position 5-7; bananas hang from the ceiling at 2-2; a light ladder stands on the floor at 9-5. The monkey can walk, carry the ladder, climb it, and grasp the bananas.

To solve this declaratively we model the world as a state, a snapshot of everything that can change:

The bananas never move, so they are not part of the state; they are a fixed fact about the world. A plan is then a sequence of actions that transforms the initial state into any state where the monkey holds the bananas. This is the classic state-space search formulation: states are nodes, actions are edges, and planning is graph search.

In Racklog we express this with two relations. %move relates a state, an action, and the resulting state. It is the complete “physics” of the monkey’s world in seven clauses. %canget is the recursive planner: from a goal state the plan is empty; from any other state the plan is one legal move followed by a plan from the resulting state, provided we have not visited that state before (the visited check is what keeps depth-first search from walking in circles forever).

Here is the complete file monkey.rkt:

Read %move the way you would read a physics textbook: each clause is one law. “If the monkey is at the ladder, on the floor, holding nothing, then climbing the ladder leaves the monkey on the ladder.” Notice how much of each clause is just the same logic variable appearing in the before-state and the after-state. The shared p in the climb clause is what guarantees the monkey and the ladder are in the same place, with no explicit equality test.

Read %canget as a two-line definition of “solvable”:

1. A state where the monkey holds the bananas is solvable with the empty plan.
2. Any other state is solvable if some move leads to an unvisited state that is itself solvable. The plan is that move prepended to the plan for the new state.

That recursive clause is the entire search algorithm. %not and %member (both built into Racklog) implement loop detection. When we finally pose the query with %which, Racklog’s backtracking search does the rest, and the logic variable plan comes back bound to the answer.

The plan is correct: jump off the couch, fetch the ladder, carry it under the bananas, climb, grasp. But look at steps 2–3 and 5–6: the monkey walks to 2-2 first (presumably to gaze longingly at the bananas), and later carries the ladder via 5-7. This is a valid plan, not the shortest one.

That detour is a direct consequence of the search strategy, and seeing it is worth more than a prettier answer. Racklog explores depth-first in clause order: at each state it tries grasp, then climb, then pick-up, then drop, then carry, then walk, then jump-down, and within walk it tries destinations in the order %location lists them. The first complete plan it stumbles into is the one printed. OPS5 had the opposite character: its conflict-resolution strategy picked which rule to fire next, and the OPS5 author shaped the plan by writing rules in a careful order; control lived in the rule set rather than in a search procedure.

If shortest plans mattered, the fix would be iterative deepening (try all plans of length 1, then 2, then 3), which guarantees the first solution found is minimal. For this tiny state space (three locations, a handful of on/holds combinations) plain depth-first search answers instantly, so we keep the simpler program.

Same problems, two tools, two philosophies:

Neither is “better.” Production rules shine when a system must react continuously to arriving facts: monitoring, diagnosis, agents. Logic programming shines when the question itself is the program: parsing, planning, constraint solving, anything naturally phrased as “find an x$ such that …”. Racklog’s particular charm is that the whole thing is just Racket, so when the logic ends (printing a plan, formatting a hand) you are back in an ordinary general-purpose language with no seams.

1. Add a %two-pair relation to draw.rkt that finds two pairs at different ranks. Test it by adding a 4 of clubs to the hand.
2. In monkey.rkt, add a second ladder at 5-7. Does the plan change? Why or why not?
3. Replace %which with %find-all in monkey.rkt to enumerate every plan. Before running it, predict whether the result is finite.
4. Rewrite the %suit< relation using ranks (club = 1, diamond = 2, …) and Racklog’s %is and %< predicates. Which version do you find clearer?
