Separate decisions, workflows and technical interactions
Any good test automation book will suggest that user interface interactions need to be minimised or completely avoided. However, there are legitimate cases where the user interface is the only thing that can actually execute a relevant test. A common example is where the architecture dictates that most of the business logic sits in the user interface layer (such applications are often called ‘legacy’ even by people who write them, but they are still being written). Another common situation is when an opaque, third-party component drives an important business process, but has no sensible automation hooks built into it. In such cases, teams often resort to record-and-replay tools with horrible unmaintainable scripts. They create tests that are so difficult to control and so expensive to maintain that it’s only possible to afford to check a very small subset of interesting scenarios. Teams in such situations often completely give up on any kind of automation after a while.
There are two key problems with such tests. One is that they are slow, as they often require a full application stack to execute. The other is that they are extremely brittle. Small user interface changes, such as moving a button on the screen somewhere else, or changing it to a hyperlink, break all the tests that use that element. Changes in the application workflow, such as requiring people to be logged in to see some previously public information, or introducing a back-end authorisation requirement for an action, pretty much break all the tests instantly.
There might not be anything we can do to make such tests run as fast as the ones below the user interface, but there are definitely some nice tricks that can significantly reduce the cost of maintenance of such tests, enough to make large test suites manageable. One of the most important ideas is to apply a three-layer approach to automation: divide business-oriented decisions, workflows and technical interactions into separate layers. Then ensure that all business decision tests reuse the same workflow components, and ensure that workflow components share technical interactions related to common user interface elements.
We’ve used this approach with many clients, from financial trading companies working with thick-client administrative applications, to companies developing consumer-facing websites. It might not be a silver bullet for all possible UI automation situations, but it comes pretty close to that, and deserves at least to be the starting point for discussions.
Key benefits
A major benefit of the three-layer approach, compared to record-and-replay tests, is much easier maintenance. Changes are localised. If a button suddenly becomes a hyperlink, all that needs to change is one technical activity. Workflows depending on that button continue to work. If a workflow gets a new step, or loses one, the only thing that needs to change is the workflow component. All technical activities stay untouched, as do any business rule specifications that use the workflow. Finally, because workflows are reused to check business decisions, it’s easy to add more business checks.
The three-layer design pattern is inspired by similar ideas from the popular page object pattern, but instead of tying business tests too tightly to current web page structures, it decouples all common types of change. Tests automated using page objects are easily broken by workflow changes that require modifications to transitions between pages or affect the order of interactions. Because of this, the three-layer approach is better for applications with non-trivial workflows.
Applications with a lot of messy user interface logic often need a good set of integration tests as well as business checks. Another big benefit of the three-layer approach is that the bottom layer, technical interactions, can be easily reused for technical integration tests. This reduces the overall cost of test maintenance even further, and allows the delivery team to automate new tests more easily.
How to make it work
Most test automation tools work with one or two layers of information. Tools such as FitNesse, Concordion or Cucumber provide two layers: the business specification and the automation code. Developer-oriented tools such as Selenium RC and unit-testing tools tend to offer only one layer, the automation code. So do tester-oriented tools. This misleads many teams into flattening their layer hierarchy too soon. Automation layers for most of these tools are written using standard programming languages, which allow for abstractions and layering. For example, using Concordion, the top-level (human readable specification) can be reserved for the business-decision layer, and the automation code below can be structured to utilise workflow components, which in turn utilise technical activity components.
Some tools, such as Cucumber, allow some basic reuse and abstraction in the test specification (top level) as well. This theoretically makes it possible to use the bottom automation layer only for technical interactions, and push the top two layers into the business-readable part of the stack. Unless your team has a great many more testers than developers, it’s best to avoid doing this. In effect, people will end up programming in plain text, without any support from modern development tool capabilities such as automated refactoring, contextual search and compilation checks.
